Offline X-Ray Inspection
Xpection 1860
A versatile X-ray machine that offers comprehensive circuit board defect detection and quality assurance for the SMT industry worldwide.
With a single closed tube and tilting features, the Xspection 1860 delivers high-resolution imaging perfect for batch inspections.
It also provides detailed statistics to help improve your SMT line process. This makes it an excellent tool for inspecting various components, including multilayer PCBs, voids, Barrel Fill (THT), and others.
| Detection Range | 16"x18" / 400mm 460mm |
| Maximum Tilt | 45° |
| Inspection Speed | Stepper Motors |
| Maximum X-Ray Power | 90kV, Min. 5µm |
| Flat Panel Detector | 5"x5" 14bit |
| Resolution | 1536px x 1536px |
| Pixel Size | 85µm |
| Optical Inspection Camera | Yes |
| Automatic Programming | Yes |
| Fiducial Recognition | Yes |
| Automatic Void Percentage Calculation | Yes |
| BGA Measuring | Yes |
| Barcode | Optional (Laser Scanner) |
| Windows 11 | Yes |
| Dimensions | (L/W/H): 950mm x 1240mm x 1780mm / 37.4in x 49in x 70in |
| Weight | 1300kg |
| Electric | AC110-240V VAC 50/60Hz |
